Product Model
Config.1: T1730
Config.2: T1731
Config.2: T1731
OS
SUNMI OS
(based on Android 13)
(based on Android 13)
Processor
Qualcomm hexa-core,
up to 2.4GHz
up to 2.4GHz
Memory
3GB RAM+32GB ROM
Display
Main: 10.1″ IPS HD, 800*1280, 300nits; 10-point capacitive touch screen.
Secondary: 4″ IPS, WVGA, 480*800, 300nits；capacitive touch screen.
Secondary: 4″ IPS, WVGA, 480*800, 300nits；capacitive touch screen.
Printer
Built-in 80mm thermal printer
Auto cutter
Print speed: 250mm/s
Service life: 150Km
Paper roll OD: 60mm
Auto cutter
Print speed: 250mm/s
Service life: 150Km
Paper roll OD: 60mm
Card Reader
Support TypeA&B card, Mifare card, Felica card;
Comply with ISO/IEC 14443, ISO 15693 standards;
Read distance 0-4cm
Comply with ISO/IEC 14443, ISO 15693 standards;
Read distance 0-4cm
Scanner
A 1MP built-in scanner for 1D/2D barcode reading
PSAM Card Slot
2*PSAM, 3.0V supported
SIM Card Slot
2*SIM, 1.8V/3.0V supported
Speaker
1* 3W
Network
2G&3G&4G
Wi-Fi
2.4GHz & 5GHz
IEEE 802.11 a/b/g/n/ac supported
IEEE 802.11 a/b/g/n/ac supported
Bluetooth
Bluetooth 2.1/3.0/4.2/5.0
and BLE supported
and BLE supported
Indicator Light
Blue (Power)
Button
1*Power button (lock screen)
1*Reset button (hidden)
1*Reset button (hidden)
Ports
3*USB 2.0 Type A port
1*RJ11 serial port
1*RJ12 cash drawer port
1*RJ45 LAN port
1*audio jack
1*power port
1*MicroUSB debug port (hidden)
1*RJ11 serial port
1*RJ12 cash drawer port
1*RJ45 LAN port
1*audio jack
1*power port
1*MicroUSB debug port (hidden)
Battery
N/A
Power Adapter
Input: AC 100~240V/1.7A
Output: DC 24V/1.5A/60W
Output: DC 24V/1.5A/60W
Weight
1.4kg
Environment
Operating temp: 0°C~40°C
Storage temp: -20°C～60°C
Storage temp: -20°C～60°C
Dimensions (L*W*H)
250*231*108mm
